Description
|
Frequency Range
|
Uplink
|
Downlink
|
|
|
900MHz
|
880 – 915MHz
|
925 – 960MHz
|
|
|
Max Gain
|
75dB±2dB
|
80dB±2dB
|
|
|
Max Output Power
|
20dBm±2dBm
|
27dBm±2dBm
|
|
|
Band width
|
Wide Band
|
||
|
Manual Gain Control
|
31dB / 1dB Step
|
||
|
ALC
|
>25dB
|
||
|
Ripple in Band
|
≤ 8dB
|
||
|
Noise Figure
|
≤ 6dB
|
||
|
VSWR
|
≤ 2.0
|
||
|
Intermodulation
|
≤ -40dBc
|
||
|
Spurious Emission
|
9KHz~1GHz
|
≤ -36dBm
|
|
|
1~12.75GHz
|
≤ -30dBm
|
||
|
Time Delay
|
≤ 1.5 μs
|
||
|
Frequency stability
|
≤ 0.01ppm
|
||
|
MTBF
|
> 50000 hours
|
||
|
Impedance
|
50 ohm
|
||
|
Power Supply
|
AC 90-264V,DC 9V/5A
|
||
|
Power LED
|
Power indicator
|
||
|
Alarm LED
|
Red
|
Self oscillation or Strong input signal
|
|
|
Green
|
Normal
|
||
|
Mechanical Specification
|
|||
|
RF Connector
|
N-Female
|
||
|
Switch
|
Power Switch,Manual Gain Control Switch
|
||
|
Cooling
|
Heatsink Convection cooling
|
||
|
Humidity
|
< 90%
|
||
|
Operating Temperature
|
-10°C ~ +55°C
|
||
|
Environment Conditions
|
IP40
|
||
|
Installation Type
|
Wall Installation
|
||
|
Size
|
268mm*58mm*189mm
|
||
|
Weight
|
< 4.1Kg
|
||
Why do you need to buy repeater/booster?
we are manufacture of signal booster, we can provide you tri band, dual band, single band products. we also can provide you all
accessories, such as indoor antenna, panel antenna, coaxial cable and so on.
accessories, such as indoor antenna, panel antenna, coaxial cable and so on.
Introduction
A mobile phone signal repeater provide the ultimate solution in any indoor area where cellular communications can not work well
due to leak of signals (but outdoor signal good). The repeater device features easy installation & operation, build-in indoor
antenna and no interference. It could also improve indoor electromagnetism environments, protract cellular battery life and reduce
radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
due to leak of signals (but outdoor signal good). The repeater device features easy installation & operation, build-in indoor
antenna and no interference. It could also improve indoor electromagnetism environments, protract cellular battery life and reduce
radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
