Specification
|
5G NETWORK
|
5G Module: Qualcomm® Snapdragon™ X55 Modem-RF System
|
|
5G network mode: SA (standalone), NSA (non-standalone)
|
|
|
5G NSA frequency band: n38/n41/n77/n78/n79
|
|
|
5G SA frequency bands: n1/n2/n3/n5/n7/n8/n12/n20/n25/n28/n38/n40/n41/n48*/n66/n71/n77/n78/n79
|
|
|
5G Protocol: 3GPP Release 15
|
|
|
5G SA Speed: 2.1Gbps/900Mbps (up to ISPs)
|
|
|
5G NSA Speed:2.5Gbps/650Mbps (up to ISPs)
|
|
|
4G NETWORK
|
LTE Category：Down Cat 16/ UP Cat 1
|
|
LTE-FDD:B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29/B30/B32/B66/B71
|
|
|
LTE-TDD: B34/B38/B39/B40/B41/B42/B43/B48
|
|
|
LTE Down 4 × 4 MIMO:B1/B2/B3/B4/B7/B25/B30/B32/B34/B38/B39/B40/B41/B42/B43/B48/B66
|
|
|
WCDMA:B1/B2/B3/B4/B5/B8/B19
|
|
|
LTE : Down 1.0 Gbps；UP 200 Mbp
|
|
|
Processor
|
Quad-core ARM Cortex A53 @ 1.0 GHz
|
|
Storage
|
16MB Flash + 128MB NAND + 2* 256MB DDR3
|
|
network port
|
1 Wan/Lan adaptive 2.5G network port, 2 Gigabit Lan ports, 1 SIM card slot (Nano-SIM）
|
|
Reset & Sync button
|
multiplex
|
|
Host size
|
108X108X216MM
|
|
Power consumption
|
<23W
|
|
AC/DC power supply
|
AC:100V-240V 50Hz/60Hz,DC:12V/2A
|
|
Operating temperature
|
0℃~40℃
|
|
humidity
|
5% to 95% (non-condensing)
|
|
processor
|
Quad-core ARM Cortex A5
|
